Headlights...I cant see diddly squat at night

ISPKI

Welding/metallurgical engineer/Metalsmith
Joined
Jul 13, 2015
Posts
756
Reaction score
345
Location
Granby CT
Relay sounds like an interesting idea. I have had alot of bad luck with aftermarket relays though, and would be hesitant to use them if the factory setup functions OK. On the other hand, I do hate that headlight switch with a passion. I have never seen an OBS with the knob still attached and my "new" truck is no exception.


The_Josh_Bear

Full Access Member
Joined
Jun 1, 2016
Posts
1,264
Reaction score
839
Location
Western WA
Relay sounds like an interesting idea. I have had alot of bad luck with aftermarket relays though, and would be hesitant to use them if the factory setup functions OK. On the other hand, I do hate that headlight switch with a passion. I have never seen an OBS with the knob still attached and my "new" truck is no exception.
The factory setup is garbage and the relay kit works very well! I got mine at brocograveyard.com and it helps a lot, along with new lenses. I didn't chime in earlier because I have an 89, not an OBS.


Mishka

Registered User
Joined
Dec 16, 2019
Posts
80
Reaction score
45
Location
Fort Knox, KY
Mine was garbage so I got some 35$ amazon led hi/low beam headlights and they've been amazing. About as bright as a new truck with LEDs.


Attachments

  • received_2698522913711208.jpeg
    225.7 KB · Views: 8

TNBrett

Full Access Member
Joined
Oct 24, 2020
Posts
430
Reaction score
374
Location
Middle Tennessee
The thing with LEDs is that you don’t need to worry about adding relays because they only draw about half the wattage of the halogens. The ones I use only draw 30 watts each as opposed to 55 watts for the stock halogens. I would avoid the “off road use only” Hella bulbs. They draw way to much current for the stock headlight switch, so you have to run relays. But, I think it’s pushing it on what the headlight bulb connector can handle. I’ve also seen the heat from those bulbs cause problems with the lenses/ housings in other applications.


ISPKI

Welding/metallurgical engineer/Metalsmith
Joined
Jul 13, 2015
Posts
756
Reaction score
345
Location
Granby CT
I polished up my headlights just to see how they would look. Sanded then up to 3000 grit and they actually cleaned up pretty ok. I installed the eagle LEDs and there is a big improvement except for one issue. One of these pictures is low beam and the other is high beam. Pretty sure I have them rotated wrong cuz it doesnt change between the two. I can see it switching but the light pattern is almost identical.
You must be registered for see images attach
You must be registered for see images attach


Selahdoor

How can I help you, or make you laugh, today?
Supporting Member
Joined
Oct 26, 2015
Posts
2,031
Reaction score
1,720
Location
Index Wa
Yep.

Pull the bulb holder out.

The back end of the holder looks like a "D".

The bulb should be installed into the housing with the flat being horizontal and on the upper part.

You must be registered for see images attach


Selahdoor

How can I help you, or make you laugh, today?
Supporting Member
Joined
Oct 26, 2015
Posts
2,031
Reaction score
1,720
Location
Index Wa
I polished up my headlights just to see how they would look. Sanded then up to 3000 grit and they actually cleaned up pretty ok. I installed the eagle LEDs and there is a big improvement except for one issue. One of these pictures is low beam and the other is high beam. Pretty sure I have them rotated wrong cuz it doesnt change between the two. I can see it switching but the light pattern is almost identical.
You must be registered for see images attach
You must be registered for see images attach
Did you try turning the headlight bulbs in the direction I suggested?

Did it make a difference?

Mine were just like yours. No difference.

Now that the bulbs are oriented correctly, and the headlights aimed correctly, they are great!

Much better light at the dim setting, and even better at the high setting.


lakesurfer

Registered User
Joined
Dec 13, 2017
Posts
60
Reaction score
49
Location
Smyrna, TN
IMO, step 1 is to fix the substandard Ford headlight wiring, so that whatever headlight solution you use gets the full benefit of voltage and current. The factory wiring runs all that high current headlight power through long, skinny wires into the dash, in/out of the switch, then all the way back to the headlights. Resistance builds up in the switch and switch connector, leading to carbon, melting, smoke, loss of voltage to the lights, and light failure. The solution is to install isolation relays so the switch only controls the relays, and the relays switch the light power using large gauge wires of your choice, over short *fused* runs from the battery. My standard bulbs performed MUCH better once this was done. And now, if I choose to upgrade to something that takes a bit more current, the wiring is in place. There are writeups on this already out there. This is one resource I used for reference: http://www.rowand.net/Shop/Tech/WiringHeadlightRelays.htm


IDIBRONCO

IDIBRONCO
Joined
Feb 5, 2010
Posts
8,781
Reaction score
7,052
Location
edmond, ks
IMO, step 1 is to fix the substandard Ford headlight wiring, so that whatever headlight solution you use gets the full benefit of voltage and current. The factory wiring runs all that high current headlight power through long, skinny wires into the dash, in/out of the switch, then all the way back to the headlights. Resistance builds up in the switch and switch connector, leading to carbon, melting, smoke, loss of voltage to the lights, and light failure. The solution is to install isolation relays so the switch only controls the relays, and the relays switch the light power using large gauge wires of your choice, over short *fused* runs from the battery. My standard bulbs performed MUCH better once this was done. And now, if I choose to upgrade to something that takes a bit more current, the wiring is in place. There are writeups on this already out there. This is one resource I used for reference: http://www.rowand.net/Shop/Tech/WiringHeadlightRelays.htm
I agree with this. Two of my trucks already have headlight relay kits installed and the third one is on the list to get one soon.


TNBrett

Full Access Member
Joined
Oct 24, 2020
Posts
430
Reaction score
374
Location
Middle Tennessee
I agree with adding relays if you’re running halogen bulbs, but they are unnecessary if you run LED’s. The LED’s draw half the current that a typical halogen does, and in my opinion throws much better light.


ISPKI

Welding/metallurgical engineer/Metalsmith
Joined
Jul 13, 2015
Posts
756
Reaction score
345
Location
Granby CT
Hey yeah so I got the new headlight lenses with the LEDS wired in. Unfortunately the LEDs have a pigtail with the half moon shaped plug at the end of the pigtail so there is no way of knowing if you have them adjust right until its night time and you have them on. Wasnt difficult to get them lined up correctly though.

Yeah, LED bulbs and clean lenses made a huge difference. I will post up a shot of what it looks like now once I find the pictures.
