My Bio Diesel beginning

[TEXCRAWLER]

Making America hungry. Getting started on my BIO Diesel operation. I'm doing the apple seed process. Everyone driving behind me is gona get hungry. Gona be able to make it for $1.17 a gallon.

75 Gallon water heater

You must be registered for see images

55 gallon drum of methonal

You must be registered for see images

pump

You must be registered for see images

Plumming is gona look like this

You must be registered for see images

Getting my piping and pump setup and should be making Bio Diesel by the weekend.

You must be registered for see images

Cooked up my 1st test bach to test my PH levels

You must be registered for see images

My setup ETA 1st bach this weekend

You must be registered for see images

You must be registered for see images

More to come!!



[h2odrx]

Looking good!!!
Don't forget to keep that 55 gal drum grounded!!! don't want to read about you on fox news!!!!



[TEXCRAWLER]

All the barrels that I using in the process are polyurithane. Should they be grounded as well as my holding tanks for biodiesel?



[RKOCH]

I started that way but found out real quick a water heater was not the way to go. If you let it settle the way you should the gylcerin will start to harden up and you will never get it out of the tank. I used 3 55 gal drums with removable tops. Processor , washer, and dryer. It is pretty elaborate to hard to explain in words. But I will snap some pics. and post.



[RKOCH]

Dude I just saw that is a GAS water heater DON"T use it!!!!!! The methanol vapors can and will esacpe a open flame in the heater is a absolute NO NO! It can and has happened and will blow up or catch and mad fire. Only use electric heating.



[TEXCRAWLER]

Dude I just saw that is a GAS water heater DON"T use it!!!!!! The methanol vapors can and will esacpe a open flame in the heater is a absolute NO NO! It can and has happened and will blow up or catch and mad fire. Only use electric heating.

I replied to your PM. NO methanol nere open flames. Its in a seperate area out of that building. I have a 55 gallon electric water heater I'm tryin to get. I wish there was a way to convert this one to electric. I'm tryin to keep it as safe as possible.



[h2odrx]

My current processor is gas not sure if I'm going to use it that way or not? someone suggested turning it upside down and using the flue for a condesor of sorts to reclaim the methanol? I'm going to use solar to heat the oil to its hotest point then maybe a small electric heater?



[RKOCH]

The methanol fumes are going to come from the processing of the oil. Not your barrel. I am talking about what you add to the batch in the processor to make the fuel when you heat it it evaporates and no matter how closed you think it is it is not. You never use a gas heater for that reason.



[TEXCRAWLER]

This is what it looked like when I put it in for processing.

You must be registered for see images

You must be registered for see images

This is my final Biodiesel and ready to put in truck.

You must be registered for see images



[RKOCH]

Good job! just keep doing they way we discussed I would hate to hear about you on the news.



[TEXCRAWLER]



[TEXCRAWLER]

This is what my complete setup looks like.

You must be registered for see images

You must be registered for see images



[TEXCRAWLER]

I may have went a bit over board but this chit can mess you up. Always work safe and responsibly. Next is gona be the fire suit.

You must be registered for see images



[NapaBavarian]

Are there still sources of WVO here? When I had to put my project on hold I quit looking...probably cost me $5000 or more in fuel since then



[RKOCH]

Your filters need to be for methanol and or alcohol vapors, a standard organic vapor filter will not work.
